The complete Tera CRD60 HD Rear Axle Assembly w/ Semi-Float provides a choice of pre-installed Super 60 ring & pinion gears, ARB air locker, and semi-float outer axles as well as inner axle shafts, and sensors.

---

The complete Tera CRD60 HD Rear Axle Assembly w/ Semi-Float provides a choice of pre-installed Super 60 ring and pinon gears, ARB air locker, and semi-float outer axles as well as inner axle shafts, and sensors. TeraFlex Tera CRD60 HD Rear Axle Housings are perfect for replacing bent, broken, or damaged axles in TJ Wrangler/Unlimited vehicles including Rubicon models. Can also be used as a direct bolt-on upgrade for Jeep owners looking to beef up the stock axles? weak areas. The exclusive Constant Radius Design (CRD) provides high ground clearance that is unaffected by pinion angle adjustments. Compatible with all Super 60 gear ratios for extreme duty applications requiring additional ring and pinion strength. Our heavy-duty axle housings feature smooth profile surfaces, axle tubes, all necessary mount brackets, control arm bushings, and more!

• Constant Radius Design (CRD) provides maximum ground clearance regardless of pinion angle Built-in ?skimmer" cuts ring gear oil halo
• increased rib gussets HD ductile iron differential cover
• raised track bar bracket Pre-tapped hole on spring perch for bump stop extensions Pre-drilled holes for limit straps
• Rear Disc Brake Conversion Kit Fixed spindle mount hub assembly Tera CRD60 specific high-pinion rear axle housing design Includes 1350 series pinion yoke 35-spline inner
• increased cover mounting area Integrated lower control arm skid plates High-flow oil passages Bottom oil drain hole for simple fluid changes Reinforced rear track bar mount
• high-load conditions High-capacity housing holds maximum amount of oil Asymmetric housing design for extra-long tube side strength Pre-installed inner axle seals Ductile cast iron housing
• forces it into the pinion bearings Outer pinion bearing pocket features a renewable oil reservoir that sends cool oil to the pinion bearing Oversized outer pinion bearing handles increased torque
• multiple mounting locations UV protected triple-stage powder coat for corrosion resistance 1/4"-thick CNC laser cut axle brackets for extreme strength Pre-installed upper control arm bushings Proper pinion angle for lifted TJ applications
• 100% engineered, designed, and built in the USA w/ new components
• Factory-style semi-float design
• 3-6" Lift features a raised pinion angle
• Pre-drilled holes for limit straps and lower spring retainers Retains all JK ESP, ABS, and speedometer sensor capability
• Retains all JK ESP, ABS, and speedometer sensor capability
• Factory-style semi-float design 3.25" O.D. x 0.375" wall DOM axle tube for superior strength
• 5x5.5" wheel bolt pattern Includes Ford & TeraFlex: Rear Disc Brake Conversion Kit
• outer axle shafts HD bearing caps increase rigidity

---

Application Summary:

Year	Make/Model
1997-2006	Jeep Wrangler
