Big Block Chevy - Use with MSD 6/7/8 Series Ignition - Red
The MSD Flying Magnet Crank Trigger uses four magnets secured in the aluminum trigger wheel that pass by a stationary non-magnetic pick-up to trigger the ignition. This "flying magnet" design produces accurate trigger signals and the non-magnetic pick-up cannot be falsely triggered. Each Flying Magnet Crank Trigger includes a two-piece mounting bracket for the non-magnetic pick-up that in most cases will work on either the passenger side or driver's side of the engine (the SB Chrysler and SB Ford brackets mount on only one side). The CNC-machined aluminum bracket securely holds the pick-up in place and is slotted to provide a wide range of timing adjustments. Spacers are included so you can mount the bracket on engines with standard motor mounts or engines with a .25" motor plate. These systems will trigger MSD 6, 7, and 8 Series Ignitions and all MSD Timing Accessories.
The MSD Flying Magnet Crank Trigger uses four magnets secured in the aluminum trigger wheel that pass by a stationary non-magnetic pick-up to trigger the ignition. This "flying magnet" design produces accurate trigger signals and the non-magnetic pick-up cannot be falsely triggered. Each Flying Magnet Crank Trigger includes a two-piece mounting bracket for the non-magnetic pick-up that in most cases will work on either the passenger side or driver's side of the engine (the SB Chrysler and SB Ford brackets mount on only one side). The CNC-machined aluminum bracket securely holds the pick-up in place and is slotted to provide a wide range of timing adjustments. Spacers are included so you can mount the bracket on engines with standard motor mounts or engines with a .25" motor plate. These systems will trigger MSD 6, 7, and 8 Series Ignitions and all MSD Timing Accessories.
- Absolutely the most accurate way to trigger the ignition.
- The non-magnetic pickup cannot be false triggered.
- Powerful magnets are embedded in a billet aluminum trigger wheel.
- Kits feature special brackets and mounting hardware for a variety of engines.
Information:
Holley Performance Emission Code 4: This part is legal for sale or use on Racing Use Only Vehicles. The following vehicles are considered Racing Use Only Vehicles: Racing Use Only Vehicles are vehicles that are used exclusively for competition that are not registered and that may never be used on the street. WARNING: It is against the law to install this part on an Emissions Controlled VehicleApplication Summary:
Year | Make/Model |
---|---|
1975 | Chevrolet Bel Air |
1975-1980 | Chevrolet C10 |
1975-1980 | Chevrolet C10 Suburban |
1975-1986 | Chevrolet C20 |
1975-1986 | Chevrolet C20 Suburban |
1975-1986 | Chevrolet C30 |
1975-1976 | Chevrolet Caprice |
1976 | Chevrolet G20 |
1975-1976 | Chevrolet G30 |
1975-1976 | Chevrolet Impala |
1976 | Chevrolet K10 |
1979-1980 | Chevrolet K10 |
1976-1978 | Chevrolet K20 |
1980 | Chevrolet K20 |
1985 | Chevrolet K20 Suburban |
1977 | Chevrolet K30 |
1980-1986 | Chevrolet K30 |
1976-1978 | Chevrolet K5 Blazer |
1975 | Chevrolet Malibu |
1975 | Chevrolet Monte Carlo |
1987-1988 | Chevrolet R30 |
1989 | Chevrolet R3500 |
1987-1988 | Chevrolet V30 |
1989 | Chevrolet V3500 |
1975-1978 | GMC C15 |
1975-1978 | GMC C15 Suburban |
1979-1980 | GMC C1500 |
1979-1980 | GMC C1500 Suburban |
1975-1978 | GMC C25 |
1975-1978 | GMC C25 Suburban |
1979-1986 | GMC C2500 |
1979-1986 | GMC C2500 Suburban |
1975-1978 | GMC C35 |
1979-1986 | GMC C3500 |
1975-1976 | GMC G25 |
1976 | GMC G35 |
1976 | GMC Jimmy |
1976 | GMC K15 |
1979-1980 | GMC K1500 |
1976-1978 | GMC K25 |
1976-1977 | GMC K25 Suburban |
1979-1986 | GMC K3500 |
1987-1989 | GMC R3500 |
1975 | GMC Sprint |
1987-1989 | GMC V3500 |
Attributes | |
ASIN | B000COON52 |
Brand | MSD, MSD |
California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
Category | Ignition, Ignition |
Color | Red, Red |
Country of Origin (Primary) | US |
Diameter | 8 in., 8" |
Emission Code | 4, 4, Off Road |
GTIN | 00085132086207 |
Harmonized Tariff Code (Schedule B) | 8511906040 |
Hazardous Material Code | N |
Life Cycle Status Code | Available to Order |
Make | GM, Chevrolet |
NAFTA Preference Criterion Code | B |
Product Type | Crank Trigger Kit, Crank Trigger Kit |
SDR Required Flag | N |
Sale Category | Ignition |
Sensor Dimensions | 3/4" x 2.25", 3/4" x 2.25" |
Sensor Type | Magnetic, Magnetic |
Series | Crank Triggers and Accessories |
Sub Category | Sensors |
Subcategory | Crank Trigger Kits and Accessories |
Trigger Type | 4X, 4X |
Warning | California Proposition 65, California Proposition 65 |
Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
Warranty Time | 12 |
Wheel Width | 3/8", 3/8" |
part type | Ignition Crank Trigger Kit |
MSD Performance 8620 Crank Trigger Kit, Fly. Magnet, BB Chevy
Product Information
- Brand: MSD Performance
- Product Number: 8620
