19 Row Oil Cooler and Fan Pack
Earls new premium quality UltraPro oil coolers are ideal for all high performance applications. These aluminum stacked plate style coolers are made using state of the art brazing techniques for a durable and long lasting premium cooler that is highly efficient w/ minimal pressure drop. These fan coolers are available in 3 sizes & feature a premium cooling fan & aluminum shroud. These coolers feature -10 AN O-ring female ports and are used with special ORB cooler fittings (-6 AN, -8 AN, -10 AN, or -12 AN) and AN hose ends. Black Finish.
  • Premium Quality High Performance Stacked Plate Style Aluminum Oil Coolers
  • Made Using State of the Art Brazing Technology
  • Highly Efficient Design w/ Minimal Pressure Drop
  • Extremely Durable Lightweight Aluminum Construction w/Black Finish
  • (3) Width Options – Narrow 8.25”, Wide 12.99”, and Extra Wide 15.94” Overall Width
  • (3) Fan Pack Style Coolers Include the Oil Cooler, Spal® Cooling Fan(s) & Shroud
  • Port Sizes: 10 AN Female Ports (Uses Existing Earls Adapter Fittings)
  • Optional Mounting Brackets – Sold Separately

Information:

Holley Performance Emission Code 5: This part is legal for sale or use on Emissions Controlled Vehicles; Uncontrolled (Non-Emissions Controlled) Vehicles; and Racing Use Only Vehicles because it does not affect vehicle emissions and is not covered by emissions regulations
Attributes
AMP Draw 4.8
Amperage Draw 4.8
Application Differential Cooler, Differential Cooler, Engine Oil Cooler, Transmission Cooler
Blade Quantity 5
Blade Style Paddle, Paddle
Blade Type Paddle
Body Width 8.250 in.
Body Width (Overall) 8.250", 8.250"
Bracket Included No
Brackets Included No, No
Brand Earl's, Earl's
California Proposition 65 No
Capacity 0.22 qt.
Category Belts and Cooling
Construction Stacked Plate - Brazed, Stacked Plate - Brazed
Cooler Fittings AT585110ERL, 585106ERL
Cooler Fittings Included No, No
Country of Origin (Primary) SE
Emission Code 5, 5
Engine HP Range 100-150, 100-150 HP
Engine Oil BTU Range 13000-17500, 13,000-17,500
Fan Diameter 4.800 in., 4.800
Fan Style Puller, Puller
Fan Type Electric, Electric
Finish Black
Fitting Centers 4.800 in., 4.800"
Fitting Number 585106ERL, 585108ERL
Fittings Included No
GTIN 00090127039113
Harmonized Tariff Code (Schedule B) 8409915085
Hazardous Material Code N
Height 5.750", 5.750"
Item Height 5.750 in.
Item Weight 3.550 lbs.
Life Cycle Status Code Available to Order
Material Aluminum, Aluminum
Max Fan CFM 342, 342
Mounting Bracket Number 200ERL
Mounting Bracket Width 7.500 in., 7.500"
Mounting Brackets 200ERL, 200ERL
NAFTA Preference Criterion Code D
Number Of Blades 5
Port Size 0.875 in. -14 Female (-10 O-Ring Boss), 7/8-14 Female (-10 O-Ring Boss)
Product Line UltraPro w/ Fan Pack, UltraPro w/ Fan Pack
Product Type Oil Cooler, Oil Cooler
Radiator Core Row Quantity 19
Rows 19 Rows
SDR Required Flag N
Shroud Material Aluminum, Aluminum
Sub Category Radiators, Coolers and Related Components
Temperature Range -40° F to 302° F, -40° F to 302° F
Thickness 5.500 in., 5.500"
Transmission Fluid BTU Range 8400-13000, 8,400-13,000
Voltage 12 V, 12V
Volume .22 Quarts, .22 Quarts
Warning California Proposition 65, California Proposition 65
Weight 3.55 Lbs, 3.55 Lbs
Width Narrow Cooler, Narrow Cooler
Width (Less Mounting Ears) 6.438 in., 6.438"
Width (in.) Narrow Cooler
part type Engine Oil Cooler
