25 Row Oil Cooler Core Black
Earls new premium quality UltraPro oil coolers are ideal for all high performance applications. These aluminum stacked plate style coolers are made using state of the art brazing techniques for a durable and long lasting premium cooler that is highly efficient w/ minimal pressure drop. These coolers are available in 30 sizes for all applications (i.e. engine oil cooler, transmission cooler, power steering cooler, valve spring cooler, differential / gearbox cooler, etc.). Three fan pack style coolers are now also available w/ a premium cooling fan & shroud. These coolers feature -10 AN O-ring female ports and are used with special ORB cooler fittings (-6 AN, -8 AN, -10 AN, or -12 AN) and AN hose ends. Earls will also now stock coolers w/ -16 AN male flares brazed on the cooler for applications that require larger ports for additional oil flow. Black Finish.
Earls new premium quality UltraPro oil coolers are ideal for all high performance applications. These aluminum stacked plate style coolers are made using state of the art brazing techniques for a durable and long lasting premium cooler that is highly efficient w/ minimal pressure drop. These coolers are available in 30 sizes for all applications (i.e. engine oil cooler, transmission cooler, power steering cooler, valve spring cooler, differential / gearbox cooler, etc.). Three fan pack style coolers are now also available w/ a premium cooling fan & shroud. These coolers feature -10 AN O-ring female ports and are used with special ORB cooler fittings (-6 AN, -8 AN, -10 AN, or -12 AN) and AN hose ends. Earls will also now stock coolers w/ -16 AN male flares brazed on the cooler for applications that require larger ports for additional oil flow. Black Finish.
- Premium Quality High Performance Stacked Plate Style Aluminum Oil Coolers
- (10) Select Sizes w/ 16 AN Male Ports Will Be Stocked (no longer special order)
- Optional Mounting Brackets – Sold Separately
- Made Using State of the Art Brazing Technology
- Highly Efficient Design w/ Minimal Pressure Drop
- Extremely Durable Lightweight Aluminum Construction w/Black Finish
- (3) Width Options – Narrow 8.25”, Wide 12.99”, and Extra Wide 15.94” Overall Width
- (10) Height Options - w/ 7 to 60 Rows (2.09” to 18.31” Tall)
- (3) Fan Pack Style Coolers Include the Oil Cooler, Spal® Cooling Fan(s) & Shroud
- Port Sizes: 10 AN Female Ports (Uses Existing Earls Adapter Fittings) or 16 AN Male Ports
Information:
Holley Performance Emission Code 5: This part is legal for sale or use on Emissions Controlled Vehicles; Uncontrolled (Non-Emissions Controlled) Vehicles; and Racing Use Only Vehicles because it does not affect vehicle emissions and is not covered by emissions regulations| Attributes | |
| Application | Differential Cooler, Differential Cooler, Engine Oil Cooler, Transmission Cooler |
| Body Width | 13.000 in. |
| Body Width (Overall) | 13.000", 13.000" |
| Bracket Included | No |
| Brackets Included | No, No |
| Brand | Earl's, Earl's |
| California Proposition 65 | No |
| Capacity | 0.55 qt. |
| Category | Belts and Cooling |
| Construction | Stacked Plate - Brazed, Stacked Plate - Brazed |
| Cooler Fittings | 585106ERL, 585106ERL, 585108ERL, 585110ERL, 585112ERL, AT585106ERL, AT585108ERL, AT585110ERL, AT585112ERL |
| Cooler Fittings Included | No, No |
| Country of Origin (Primary) | SE |
| Emission Code | 5, 5 |
| Engine HP Range | 325-425, 325-425 HP |
| Engine Oil BTU Range | 33100-46000, 33,100-46,000 |
| Finish | Black |
| Fitting Centers | 9.530 in., 9.530" |
| Fitting Number | 585106ERL, 585108ERL |
| Fittings Included | No |
| GTIN | 00090127040034 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Height | 7.600", 7.600" |
| Item Height | 7.600 in. |
| Item Weight | 3.400 lbs. |
| Life Cycle Status Code | Available to Order |
| Material | Aluminum, Aluminum |
| Mounting Bracket Number | 400ERL |
| Mounting Bracket Width | 12.200 in., 12.200" |
| Mounting Brackets | 400ERL, 400ERL |
| NAFTA Preference Criterion Code | D |
| Port Size | 0.875 in. -14 Female (-10 O-Ring Boss), 7/8-14 Female (-10 O-Ring Boss) |
| Product Line | UltraPro, UltraPro |
| Product Type | Oil Cooler, Oil Cooler |
| Radiator Core Row Quantity | 25 |
| Rows | 25 Rows |
| SDR Required Flag | N |
| Sub Category | Radiators, Coolers and Related Components |
| Temperature Range | -40° F to 302° F, -40° F to 302° F |
| Thickness | 2.000 in., 2.000" |
| Transmission Fluid BTU Range | 16000-27000, 16,000-27,000 |
| Volume | .55 Quarts, .55 Quarts |
| Weight | 3.40 Lbs, 3.40 Lbs |
| Width | Wide Cooler, Wide Cooler |
| Width (Less Mounting Ears) | 11.125 in., 11.125" |
| Width (in.) | Wide Cooler |
| part type | Engine Oil Cooler |
Earl's Performance Plumbing 425ERL 25 ROW ULTRAPRO COOLER WIDE BLACK
Product Information
- Brand: Earl's Performance Plumbing
- Product Number: 425ERL
