Tough Stainless Steel Wire Braid-Protected Synthetic Rubber Hose. Easy to Cut and Assemble. Accepts Swivel-Seal, Auto Fit & Auto-Crimp Hose Ends.
A high quality stainless steel braided hose at a price competitive with the imports. Earl's AUTO-FLEX stainless steel braid-protected synthetic rubber hose is manufactured to our specifications in the U.S.A. Earl's AUTO-FLEX hose features a recommended temperature range and maximum operating pressure equal to our racing premium quality Perform-O-Flex hose...at a much better price. A partial coverage textile inner braid is imbedded in the liner during manufacture. The hose is finished with a full coverage stainless steel braid which is bonded to the reinforced liner. The liner is known as H.T.E ( not to be confused with PTFE ) and it is the highest quality of synthetic neoprene liner on the market. Continuous use temperature rating is - 40 to + 350 degrees F. Auto-Flex hose is intended for use with Swivel-Seal, Auto-Fit and Auto-Crimp hose ends only. No other Earl's hose ends are intended for use with Auto-Flex hose. The use of other manufacturers hose ends is also not recommended with this hose as it does not work with lower quality import fittings. PSI rating is determined by many factors including hose end in use and assembly method.
A high quality stainless steel braided hose at a price competitive with the imports. Earl's AUTO-FLEX stainless steel braid-protected synthetic rubber hose is manufactured to our specifications in the U.S.A. Earl's AUTO-FLEX hose features a recommended temperature range and maximum operating pressure equal to our racing premium quality Perform-O-Flex hose...at a much better price. A partial coverage textile inner braid is imbedded in the liner during manufacture. The hose is finished with a full coverage stainless steel braid which is bonded to the reinforced liner. The liner is known as H.T.E ( not to be confused with PTFE ) and it is the highest quality of synthetic neoprene liner on the market. Continuous use temperature rating is - 40 to + 350 degrees F. Auto-Flex hose is intended for use with Swivel-Seal, Auto-Fit and Auto-Crimp hose ends only. No other Earl's hose ends are intended for use with Auto-Flex hose. The use of other manufacturers hose ends is also not recommended with this hose as it does not work with lower quality import fittings. PSI rating is determined by many factors including hose end in use and assembly method.
- Stainless Braid
- Protects Synthetic Rubber Hose
- Competitive Price
- Meets USA Specifications
- Textile Braid In Hose Liner
- Desirable Flexibility
- Clean and Fast Flowing
Information:
Holley Performance Emission Code 5: This part is legal for sale or use on Emissions Controlled Vehicles; Uncontrolled (Non-Emissions Controlled) Vehicles; and Racing Use Only Vehicles because it does not affect vehicle emissions and is not covered by emissions regulations| Attributes | |
| ASIN | B0002M93TK |
| Brand | Earls, Earl's |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Air and Fuel Delivery |
| Color | Silver |
| Compatible Hose End | Auto-Crimp, Auto-Fit, Econ-O-Fit, Swivel-Seal |
| Compatible Hose Ends | Swivel-Seal, Auto-Crimp |
| Country of Origin (Primary) | US |
| Emission Code | 5, 5 |
| Fluid Type | Automatic Transmission Fluid, Coolant, Diesel, E85, Methanol/Alcohol, Oil, Pump Gas, Race Gas |
| Fluid Type Rating - Automatic Transmission Fluid | 5 out of 5 Rating, 5 out of 5 Rating |
| Fluid Type Rating - Coolant | 5 out of 5 Rating, 5 out of 5 Rating |
| Fluid Type Rating - Diesel | 2 out of 5 Rating, 2 out of 5 Rating |
| Fluid Type Rating - E85 | 2 out of 5 Rating, 2 out of 5 Rating |
| Fluid Type Rating - Methanol/Alcohol | 1 out of 5 Rating, 1 out of 5 Rating |
| Fluid Type Rating - Oil | 5 out of 5 Rating, 5 out of 5 Rating |
| Fluid Type Rating - Pump Gas | 2 out of 5 Rating, 2 out of 5 Rating |
| Fluid Type Rating - Race Gas | 3 out of 5 Rating, 3 out of 5 Rating |
| Fluid Type Rating - Vacuum | 5 out of 5 Rating, 5 out of 5 Rating |
| GTIN | 00021432480703 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Hose Family | Auto-Flex, Auto-Flex |
| Hose Length | 20 ft., 20 Feet |
| Hose Outer Material | Stainless Steel Braided, Stainless Steel |
| Hose Size | 12AN, 12 AN |
| I.D. to O.D. Concentricity | 0.020 in. |
| I.D. to O.D. Concentricity Range | .020 in., .020" |
| Inside Diameter | 0.665 in. to 0.721 in., .665" TO .721" |
| Inside Diameter (in.) | 0.6875 |
| Inside Diameter to Outside Diameter Concentricity | 0.020 in. |
| Length | 20 ft. |
| Life Cycle Status Code | Available to Order |
| Material | Braided Stainless Steel |
| Max Vacuum | 27 in Hg, 27 in Hg |
| Max Working PSI | 500 PSI, 500 PSI |
| Maximum Working PSI | 500 |
| Min. Bend Radius | 4.5 in., 4.5" |
| Minimum Bend Radius | 4.500 in. |
| NAFTA Preference Criterion Code | B |
| Outside Diameter | 0.915 in. to 0.961 in., .915" TO .961" |
| Outside Diameter (in.) | 0.9375 |
| Product Length | 20 ft. |
| Product Type | Hose, Hose |
| SDR Required Flag | N |
| Size | 12AN |
| Sub Category | Fuel Storage |
| Submersible in Fuel | No, No |
| Temperature | -40-350° F |
| Temperature Range | -40° to 350° F, -40° to 350° F |
| Vacuum | 0-27 in. Hg |
| Warning | California Proposition 65, California Proposition 65 |
| part type | Fuel Hose |
Earl's Performance Plumbing 320012ERL 20 Ft. -12 Auto-Flex CHECK 300012ERL FOR
Product Information
- Brand: Earl's Performance Plumbing
- Product Number: 320012ERL
