Centerforce(R) II Clutch Series utilizes our centrifugal weights and patented machining processes for superb holding power and maximum clutch life.
The Centerforce(R) Dual Friction(R) Clutch Series is a performance matched pressure plate & disc combination featuring the patented Centerforce centrifugal weight system (where applicable) and specialized machining processes to provide a performance clutch that offers exceptional street characteristics, while offering outstanding holding-capacity and durability. Furthermore, the Centerforce Dual Friction disc has an organic full facing on one side for longevity and an organic segmented facing on the other side providing increased holding capacity. Some applications have the organic segmented facings of both sides. The Dual Friction clutch is engineered for those who are looking for the ultimate in street/strip holding power and performance without sacrificing pedal effort and driver control. While the Dual Friction has been engineered primarily as a street clutch it can be used in mild competition applications.
Application Summary:
| Year |
Make/Model |
| 2007-2014 |
Toyota FJ Cruiser |
| 2005-2015 |
Toyota Tacoma |
| Attributes |
| Alignment Tool Included |
Yes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
11, 279.4 |
| Counterweight Assist |
YES |
| Country of Origin (Primary) |
US |
| Crankshaft Bolt Hole Quantity |
8 |
| Disc Material |
Organic |
| Disc Type |
Full Face |
| Disc Type Sprung Solid |
Sprung |
| Emission Code |
Legal US |
| GTIN |
00788442036763 |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Input Shaft Diameter |
1-1/8 |
| Input Spline Quantity |
21 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled |
| Material |
Cast Iron Pressure Plate / Organic Friction |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Out of Package Weight |
23.2 |
| Pilot Bushing Included |
Yes |
| Release Bearing Included |
Yes |
| Ring Gear O.D. |
13.195 |
| Ring Gear Tooth Count |
129 |
| SDR Required Flag |
N |
| Tooth Quantity |
129 |
| Torque Capacity |
430 |
| Warranty Time |
12 |
